Suitable for

Meat

Gastronomy

Dairy products

Cured meats

Snack

tradurre

GENERAL FEATURES

  • Technology, design and production “Made in Italy”
  • Reduced dimensions (only 890 mm depth)
  • Ideal for placement in any location
  • Low energy consumption and low enviromental impact
  • White prepainted sheet metal tank (suitable for food contact) with high-pressure injected CFCs-free polyurethane insulation (density 40 Kg / m³)
  • With straight tempered glass (VD)
  • Front glass opening
  • Built-in unit (CG)
  • Gas R290
  • Not multiplexable
  • Easy installation, ready to use

Standard set-up

Thermoformed and insulated side walls (thickness 40 mm each).
Tempered side glass pre-arranged for intermediate shelf.
Electronic control panel.
Refrigerated storage with doors.
Led ceiling light.
Tempered glass intermediate shelf with supports.
Stainless steel working top with base channel to fit rear plexiglass sliding doors (optional).
Stainless steel display surface.
Automatic water evaporation system.
Off-cycle defrosting.
Standard packaging: pallet + nylon (wooden crate on request).

Available accessories

Rear plexiglass sliding doors;
Electric defrosting kit;
Kit of no. 4 castors.



TECHNICAL FEATURES
R290

R290

Typology of refrigeration
Semi-ventilated (SV)


Available sizes
LENGHTS mm:
100
L 1040
150
L 1520
200
L 2000
250
L 2480
300
L 2960


DEPTH 890 mm


Operating temperature

+ 2°C
+ 5°C



- Testing data: temperature + 25°C / relative humidity 60%


Standard RAL colours

FRONT PANEL

1018
3020
5013
6026
9005
1028
2008
5024
6019
9010



STANDARD SIDE WALLS
WHITE
GREY
BLACK
