Suitable for

Meat

Gastronomy

Dairy products

Cured meats

Snack

tradurre

GENERAL FEATURES

  • Technology, design and production “Made in Italy”
  • Reduced dimensions (only 780 mm depth)
  • Ideal for placement in any location
  • Low energy consumption and low enviromental impact
  • White prepainted sheet metal tank (suitable for food contact) with high-pressure injected CFCs-free polyurethane insulation (density 40 Kg / m³)
  • With straight tempered glass (VD)
  • Front glass opening
  • Built-in unit (CG)
  • Gas R290
  • Not multiplexable
  • Easy installation, ready to use

Standard set-up

Thermoformed and insulated side walls (thickness 40 mm each).
Tempered side glass pre-arranged for intermediate shelf.
Electronic control panel.
Refrigerated storage with doors.
Led ceiling light.
Tempered glass intermediate shelf with supports;
Stainless steel working top with base channel to fit rear plexiglass sliding doors (optional).
Stainless steel display surface.
Automatic water evaporation system.
Off-cycle defrosting.
Standard packaging: pallet + nylon (wooden crate on request).

Available accessories

Rear plexiglass sliding doors;
Electric defrosting kit;
Kit of no. 4 castors.



TECHNICAL FEATURES
R290

R290

Typology of refrigeration
Semi-ventilated (SV)


Available sizes
LENGHTS mm:
100
L 1040
150
L 1520
200
L 2000
250
L 2480
300
L 2960


DEPTH 780 mm


Operating temperature

+ 2°C
+ 5°C



- Testing data: temperature + 25°C / relative humidity 60%


Standard RAL colours

FRONT PANEL

1018
3020
5013
6026
9005
1028
2008
5024
6019
9010



STANDARD SIDE WALLS
WHITE
GREY
BLACK
